Profesjonalna obcinarka do włókien światłowodowych INNO D2

Profesjonalna obcinarka do włókien światłowodowych INNO D2

Producent: INNO InstrumentDostępność: Dostępny

Kod produktu: XB-CLEAVER-D2Zapytaj o produkt

2 507,58 zł z VAT
2 038,68 zł netto
przechowalnia

Description



INNO D2 High Precision Cleaver is a handheld type cleaver with extremely lightweight and compact size. It is installed with universal holder, which is applicable to 250μm fiber cable, 900μm fiber cable, flat cable, and fiber jumper cable. The blade provides over 48,000 cleaves by easy and simple blade position selection. D2 High Precision Cleaver is a small, portable, and easy cleaver to use in the FTTx field.


Features



Extremely fitted hand-held type cleaver with small, compact size and light weight.
Easy two-step operation to complete the cleaving.
With patent universal holder, applicable to 250μm fiber cable, 900μm fiber cable, flat cable, and fiber jumper cable
Smart design of pressure pads preventing the fiber from damage by the return of the blade carriage.
Each point of the blade can be used not only over 3000 times, but each blade has 16 cutting points, providing over 48,000 cleaves.
Made of magnesium alloy materials, giving high strength and stability. Small, compact size and lightweight.



    Size and Weight



    Height: 2.38 inches (60.69 mm)
    Width: 3.25 inches (82.65 mm)
    Depth: 3 inches (76.52 mm)
    Weight: 0.53 pounds (242 grams)


    Universal Holder




      D2 can be worked with multiple optical holders applicable to 250μm fiber cable, 900μm fiber cable, flat cable, and fiber jumper cable. With patented fiber holder, it does not require to replace cleaver holder for use of each difference fiber.



    BROCHURE :  USER’S MANUAL :


      Specifications


      Technical Specification
      Dimension82.65W*76.52D*60.69H(mm)
      Weight242g
      Fiber Diameter80µm~ 125µm
      Cleaver Length9~20mm (Single Fiber)
      Cleaver AngleLess than 0.5 Degrees with single fiber
      Life Span of BladeTotal 48,000  cleaves (1,000 fiber for 1 step *total 16 steps* 3 heights)
      Operation Steps2
      Reclaim FunctionBlade pushback
      Holder Universal holder
      Applicable Fiber Type 250µm fiber cable, 900µm fiber cable, flat cable, and fiber jumper cable


        Package

         Model NO.   QTY.
        D2 High Precision Cleaver D21
        Product Certificate      -1
        Instruction Manual-         1
        M2 L Wrench -1
        Karabiner-1
        Case-1
        Box Case-1
