Patchcord ConnLink SILVER LC Uniboot/UPC-LC Uniboot/UPC MM OM4 DUPLEX 3 m 2.0 mm TURQUOISE LSZH

The ConnLink SILVER LC Uniboot/UPC–LC Uniboot/UPC MM OM4 Duplex 2.0 mm TURQUOISE LSZH fibre optic patchcord is a modern solution designed for high-density network environments, where efficient cable management and space optimization are essential.

The use of LC Uniboot technology significantly reduces the space required for cabling compared to standard duplex patchcords. The special round cable design with a 2.0 mm diameter integrates two fibres within a single jacket, resulting in improved organization, better airflow in rack cabinets, and enhanced infrastructure visibility.

The patchcord is manufactured in the OM4 multimode standard, enabling very high-speed data transmission, making it ideal for modern data centers, LAN networks, and high-bandwidth installations. LC/UPC Uniboot connectors ensure low insertion loss and stable transmission performance.

Thanks to the polarity switching function without the need for re-termination, installation and configuration are quick and convenient. Additionally, the pull-proof design increases mechanical durability, while the LSZH (Low Smoke Zero Halogen) jacket ensures safe use in indoor environments by minimizing smoke and toxic gas emissions in case of fire.

Key features:

• LC Uniboot/UPC connectors - compact design for easier cable management

• Duplex cable in a single round jacket (Ø 2.0 mm)

• OM4 multimode fibre - supports high-speed transmission

• Polarity switching without re-termination

• Low insertion loss (≤ 0.30 dB) and high return loss (≥ 35 dB)

• LSZH jacket - enhanced fire safety

• High flexibility and mechanical durability (pull force up to 100 N)

• Operating temperature range: -20°C to +70°C.
