SFP28 FC OPTEC 32G SM LC (10km) TX1310 DDM

The OPTEC 32G SFP28 FC optical module is a high-performance transceiver designed for data transmission in Fibre Channel networks with throughput up to 32 Gb/s. The module uses single-mode fiber (SMF) and transmission at a wavelength of 1310 nm, providing a stable connection over distances up to 10 km via an LC Duplex connector.

The transceiver is designed for use in SAN (Storage Area Network) environments, data centers, and Fibre Channel backbone connections. It is compatible with modern storage infrastructure and networking equipment.

The module is equipped with DDM (Digital Diagnostic Monitoring), enabling real-time monitoring of key operating parameters such as temperature, supply voltage, transmit power, and receive power. Digital diagnostics support simplifies link monitoring and increases overall system reliability.

Thanks to the compact SFP28 form factor and hot-swap capability, the module can be installed or replaced without powering down the equipment. Low power consumption and compliance with Class 1 laser safety and RoHS standards make it a reliable solution for professional ICT environments.

Key Features:

• 32G Fibre Channel SFP28 transceiver

• Transmission up to 10 km over single-mode fiber (SMF)

• TX1310 nm wavelength

• LC Duplex connector

• Supports 32G / 16G / 8G FC data rates

• DDM/DOM digital diagnostic monitoring

• Hot-plug capability for replacement during operation

• Low power consumption

• Designed for SAN and Data Center applications

• Compliant with SFF-8472 and FC-PI-6 standards.
