Telecommunication underground cable chamber MIKRO

MIKRO cable telecommunication chambers are compact solutions designed for protecting small splice closures (up to Ø170 mm in diameter) and for storing cable slack of various types: power, electrical, traffic signaling, telecommunications, low-current, ICT, control, fiber optic, and copper cables.

Thanks to their compact design, they are ideal for use in limited spaces such as cable manholes, underground installations, basements, and other technical infrastructure elements. They also enable cable routing in areas with a small bending radius.

MIKRO chambers feature four flat side surfaces that allow the insertion of ducts with diameters of Ø32 mm and Ø40 mm. Installation can be carried out using standard mounting components such as rubber seals or half-couplings, including directly on-site.

Compared to the ZZ-PE-1 model, MIKRO chambers feature:

• Smaller dimensions

• Reduced splice chamber diameter

• Lower weight.

Applications:

• Construction and expansion of telecommunications networks

• Protection of splice closures and fiber optic cable slack

• Backbone installations, branching points, and cable route terminations.

Key advantages:

• Lightweight for easy transport and installation

• Excellent sealing performance

• Quick and easy installation

• Suitable for harsh environments and limited spaces

• Ability to route cables in tight bending radius areas

• Easy infrastructure expansion

• Smooth surface for easy cleaning

• High durability and resistance to corrosion and chemicals

• Resistance to low temperatures

• Recyclable.

Shipping information:

• Quantity per master carton: 1 pc

• Maximum per courier shipment (UPS): 1 pc

• Maximum per EUR1 pallet: 6 pcs

• Maximum per EUR2 pallet: 12 pcs.
